Axon™ Cladding

Bring drama and detail to your walls with vertical lines

Product Details

Introduce drama and detail to your walls with the clean vertical lines of Axon™ Cladding. Axon™ Cladding is a range of vertically grooved panels which incorporate the beauty and fine detail of painted vertical joint timber with the benefits of Hardie™ fibre cement.

Axon™ Cladding provides the efficiency of a large panel and comes in a range of heights to suit common wall sizes, which helps to reduce waste. Featuring a stepped shiplap joint on the long edges for easy installation, it can be gun nailed and cut cleanly with a circular saw using a dust-reducing fibre cement blade.

Axon™ Cladding is available in two groove spacing options to give the appearance of narrow and wide board sizes. Axon™ Cladding 133mm Smooth and Axon™ Cladding 400mm Smooth are smooth textured panels with vertical grooves spaced 133mm and 400mm apart respectively. Axon™ Cladding 133mm Grained has a textured finish to evoke that of timber.

Key Features

  • The vertical 9mm wide grooves imitate vertical joint timber cladding or paneling
  • Shiplap joints remove the need for joint setting to help speed up construction
  • Fire resistant - adheres to bushfire attack level BAL40
  • Resistant to rot, and damage from termites and moisture
  • Can be installed to timber or light gauge steel frames
  • CodeMark certified
  • 25-year product warranty

australian-made-logo

Introduce drama and detail to your walls with the clean vertical lines of Axon™ Cladding. Axon™ Cladding is a range of vertically grooved panels which incorporate the beauty and fine detail of painted vertical joint timber with the benefits of Hardie™ fibre cement.

Axon™ Cladding provides the efficiency of a large panel and comes in a range of heights to suit common wall sizes, which helps to reduce waste. Featuring a stepped shiplap joint on the long edges for easy installation, it can be gun nailed and cut cleanly with a circular saw using a dust-reducing fibre cement blade.

Axon™ Cladding is available in two groove spacing options to give the appearance of narrow and wide board sizes. Axon™ Cladding 133mm Smooth and Axon™ Cladding 400mm Smooth are smooth textured panels with vertical grooves spaced 133mm and 400mm apart respectively. Axon™ Cladding 133mm Grained has a textured finish to evoke that of timber.

Key Features

  • The vertical 9mm wide grooves imitate vertical joint timber cladding or paneling
  • Shiplap joints remove the need for joint setting to help speed up construction
  • Fire resistant - adheres to bushfire attack level BAL40
  • Resistant to rot, and damage from termites and moisture
  • Can be installed to timber or light gauge steel frames
  • CodeMark certified
  • 25-year product warranty

australian-made-logo

...

Product Details

Introduce drama and detail to your walls with the clean vertical lines of Axon™ Cladding. Axon™ Cladding is a range of vertically grooved panels which incorporate the beauty and fine detail of painted vertical joint timber with the benefits of Hardie™ fibre cement.

Axon™ Cladding provides the efficiency of a large panel and comes in a range of heights to suit common wall sizes, which helps to reduce waste. Featuring a stepped shiplap joint on the long edges for easy installation, it can be gun nailed and cut cleanly with a circular saw using a dust-reducing fibre cement blade.

Axon™ Cladding is available in two groove spacing options to give the appearance of narrow and wide board sizes. Axon™ Cladding 133mm Smooth and Axon™ Cladding 400mm Smooth are smooth textured panels with vertical grooves spaced 133mm and 400mm apart respectively. Axon™ Cladding 133mm Grained has a textured finish to evoke that of timber.

Key Features

  • The vertical 9mm wide grooves imitate vertical joint timber cladding or paneling
  • Shiplap joints remove the need for joint setting to help speed up construction
  • Fire resistant - adheres to bushfire attack level BAL40
  • Resistant to rot, and damage from termites and moisture
  • Can be installed to timber or light gauge steel frames
  • CodeMark certified
  • 25-year product warranty

australian-made-logo

Introduce drama and detail to your walls with the clean vertical lines of Axon™ Cladding. Axon™ Cladding is a range of vertically grooved panels which incorporate the beauty and fine detail of painted vertical joint timber with the benefits of Hardie™ fibre cement.

Axon™ Cladding provides the efficiency of a large panel and comes in a range of heights to suit common wall sizes, which helps to reduce waste. Featuring a stepped shiplap joint on the long edges for easy installation, it can be gun nailed and cut cleanly with a circular saw using a dust-reducing fibre cement blade.

Axon™ Cladding is available in two groove spacing options to give the appearance of narrow and wide board sizes. Axon™ Cladding 133mm Smooth and Axon™ Cladding 400mm Smooth are smooth textured panels with vertical grooves spaced 133mm and 400mm apart respectively. Axon™ Cladding 133mm Grained has a textured finish to evoke that of timber.

Key Features

  • The vertical 9mm wide grooves imitate vertical joint timber cladding or paneling
  • Shiplap joints remove the need for joint setting to help speed up construction
  • Fire resistant - adheres to bushfire attack level BAL40
  • Resistant to rot, and damage from termites and moisture
  • Can be installed to timber or light gauge steel frames
  • CodeMark certified
  • 25-year product warranty

australian-made-logo

...

Features & Benefits

Speed of Installation

Speed of Installation

Gun-nail to timber frames or screw to light gauge steel frames. Pre-primed and ready for paint.

Fire Resistant

Fire Resistant

Adheres to bushfire attack level requirements to BAL40. Achieves a fire resistance level (FRL) of up to 60 minutes when used with Hardie™ Smart Fire & Acoustic Wall Systems.

Timber Look

Timber Look

Fibre cement with the charm of timber, and is resistant to warping, swelling and movement to help retain its looks for longer.

Case Studies & News

Product Specifications

Product Code
Description
Length (mm)
Width (mm)
Thickness (mm)
Surface Texture
Groove Spacing (mm)
Effective Cover Per Unit (m2)
Effective Width (mm)
Coverage Per Pack (m2)
Weight Per m2*
Weight Per Unit**
Pack Weight (kg)***

403931

Axon Cladding 133mm Smooth

2450

1200

9

Smooth

133

2.94

1200

88.2

13

38.1

1195

404417

Axon Cladding 400mm Smooth

2450

1200

9

Smooth

400

2.94

1200

88.2

13

38.1

1195

404418

Axon Cladding 400mm Smooth

2750

1200

9

Smooth

400

3.3

1200

99

13

42.8

1335

403932

Axon Cladding 133mm Smooth

2750

1200

9

Smooth

133

3.3

1200

99

13

42.8

1335

404419

Axon Cladding 400mm Smooth

3000

1200

9

Smooth

400

3.6

1200

108

13

46.7

1455

403933

Axon Cladding 133mm Smooth

3000

1200

9

Smooth

133

3.6

1200

108

13

46.7

1455

404512

Axon Cladding 133mm Grained

3000

1200

9

Grained

133

3.6

1200

108

13

46.7

1455

404979

Axon Cladding 133mm Smooth

3600

1200

9

Smooth

133

4.32

1200

129.6

13

56

1730

* M2 weight includes on the wall product only weight taking into account effective coverage. This excludes fasteners, sealants and other accessories.

** Piece weight covers the physical product weight per plank/sheet.

*** Pack weight includes all product and packaging in a full pallet.
